Lenze EPL 10200 Series User Manual

F
unction control Drive
P
L
C
Make the connection between the PC and Drive PLC and the PC system bus module ONLY when the
equipment is switched off !
0
l
D
rive
PLC
Developer S
tudio
GND
LOW
HI
X5
120Ω
+18 … 30 VDC / 0 V
1
4
3
2
?
82plc017
Step Note See

Plug the copy-protection
dongle into LPT1 or LPTx
 “Drive PLC Developer Studio - Getting started”, chapter 2.2
ó
Connect the PC system bus
module
l Do not forget the bus termination resistor (120
Ω
) 0 !
l Follow the instructions for the system bus module.
ì
Switch on the supply voltage
for the Drive PLC.
The permitted voltage is + 18 ... 30 V DC
7
ö
Switch on the PC Start the Drive PLC Developer Studio (DDS) software.
Set up the communication
parameters
 “Drive PLC Developer Studio - Getting started”, Chapter
4.4.2
Load the project example  “Drive PLC Developer Studio - Getting started”, Chapter 4.4
Start program  “Drive PLC Developer Studio - Getting started”, Chapter
4.4.4
Are there any faults during commissioning or regular operation ?
?
?
