Technical data
2

MA DrivePLC DE/EN/FR 1.0
3
General data / Application conditions
Approvals UL 508: Industrial Control Equipment (in preparation)
DC voltage supply
Vol ta ge +18 VDC ... 30 VDC
D
C
v
o
l
t
a
g
e
s
u
p
p
l
y
Current 200 mA at +24 V (without load at the outputs)
Ambient temperature
transport -25 °C ... +70 °C
A
m
b
i
e
n
t
t
e
m
p
e
r
a
t
u
r
e
storage -25°C...+60°C
Operation 0°C...+55°C
Permissible mounting positions vertical
Installation space ≥
100 mm above and below
Type of protection IP 20
PLC functionality
Field Number Description Data
Inputs
digital 8 Free inputs +24VDC/8mAper
input
Reading and writing of the
inputs:
Shortest reading cycle: 1 ms
(dependingonthesitewhere
the process map is
generated)
analog 3 Free inputs
(10 bit + sign)
±10 V
Outputs
digital 4 Free outputs +24 VDC/max.1A
per output
Updating the outputs:
shortest update cycle is 1 ms
(dependingonthesitewhere
the process map is
generated)
analog
1 Voltage output (10 bits +
sign)
±10 V/max. 2mA
1 Current output
(10 bits + sign)
±20 mA
