Terminal strip wiring - easy and safe
3
6
MA DrivePLC DE/EN/FR 1.0
The terminal strips that are supplied have been tested to the specifications of
l
DIN VDE 0627:1986-06 (in parts)
l
DIN EN 60999:1994-04 (in parts)
Features tested, amongst others, are: mechanical , electrical and thermal stress, vibration, damage to
conductors, loose conductors, corrosion and ageing.
Stop!
l
Wire up the terminal strips before plugging them on!
l
Plug on or pull off the strips ONLY when the instrument is disconnected from the
supply power!
l
Unused terminal strips should also be plugged on - to protect the contacts!
8200vec015
Abb. 1-16
Tip!
The wiring may also be carried out without bootlace ferrules - without any restrictions.
