32
11.5. Change of the distance footrest - seat cushion and angle
adjustment of the footrest
11.6. Adjustment of the armrest height/angle
To adjust the height or angle, please
refer to the following:
Height adjustment
To lower the armrest, unscrew screw
A. To increase the height, tighten
screw A.
Angle adjustment
To lower the angle, unscrew screw B.
To increase the angle, tighten screw
B.
The footrest will be adjusted with
(optional w/o) tools.
To change the height of the footrest,
release the screw (A). Now you can
set the footrest to the necessary
height.
Tighten the screw back in place.
On both sides there are 4 holes (B)
you can use to adjust the height.
The angle of the footrest plate is
adjustable by turning on the screw
(C).
If you turn the screw clockwise, the
plate is rising, if you turn the screw
counter clockwise, the plate is
lowering.
To ensure that the screw does not
work loose, we recommend mounting
the screw with thread locker.
