EXTERNAL EQUIPMENT SETUP
EXTERNAL EQUIPMENT SETUP
44
OTHER A/V SOURCE SETUP
AV IN 2
VIDEO
AUDIO
L(MONO)
R
H/P
IN 4
USB IN 1 USB IN 2
L R
VIDEO
Camcorder
Video Game Set
1. How to connect
1
Connect the AUDIO/VIDEO jacks
between TV and external equipment.
Match the jack colors
.
(
Video = yellow, Audio Left = white, and
Audio Right = red
)
2. How to use
󰪗
Select the AV2 input source on the TV
using the
INPUT button on the remote
control.
󰪗
If connected to AV IN 1 input, select the
AV1 input source on the TV.
󰪗
Operate the corresponding external
equipment.
