Plasma TV Models
S-Video Input
Connect S-Video out from an
S-VIDEO device.
Audio/Video Input
Connect audio/video output
from an external device to
these jacks.
AV IN 3V IN 3
L/L/MONOMONO
R
AUDIOAUDIO
VIDEOVIDEO
S-VIDEOS-VIDEO
AUDIO
VIDEO
AV 1 AV 2
EJECT
PCMCIA
CARD SLOT
RS-232C IN
ANTENNA
IN
AV IN 3
L/MONO
R
AUDIO
VIDEO
S-VIDEO
RGB(PC)
AUDIO
(RGB/DVI)
RGB IN
COMPONENT IN
AUDIO
AUDIO
VIDEO
VIDEO
AV 1
V 1
AV 2
V 2
EJECT
EJECT
PCMCIA
PCMCIA
CARD SLOT
CARD SLOT
RS-232C IN
RS-232C IN
(CONTROL & SERVICE)
HDMI/DVI IN
12
HDMI IN
ANTENNA
IN
(OPTICAL)
DIGITAL AUDIO OUT
1 32
9
PCMCIA (Personal Computer Memory Card
International Association) Card Slot
(This feature is not available in all countries.)
HDMI Input
Connect a HDMI signal to HDMI IN.
Or DVI(VIDEO)signal to HDMI/DVI port with DVI
to HDMI cable.
DIGITAL AUDIO OUT (OPTICAL)
Connect digital audio from various types of equip-
ment.
Note: In standby mode, these ports do not work.
Antenna Input
Connect over-the-air signals to this jack.
RS-232C IN (CONTROL & SERVICE) PORT
Connect to the RS-232C port on a PC.
Component Input
Connect a component video/audio device to
these jacks.
RGB/DVI Audio Input
Connect the monitor output from a PC to the
appropriate input port.
Euro Scart Socket (AV1/AV2)
Connect scart socket input or output from an
external device to these jacks.
Power Cord Socket
This TV operates on an AC power. The voltage is
indicated on the Specifications page. Never
attempt to operate the TV on DC power.
1
2
3
4
5
6
7
8
9
84 5 6 7
BACK PANEL INFORMATION
A
This is a simplified representation of the back panel. Image shown may be somewhat different from your TV.
PREPARATION
