LG 55UK6500AUA Service Manual

- 12 -
Copyright © LG Electronics Inc. All rights reserved.
Only for training and service purposes.
3. Vx1
I2C_ A6
Vx1 8Lane 51P
2
2
C
A
2
C
H n
Panel
3840x2160@60p
H
LOCKAn
I
2
C
A
6
6
6
DATA_FORMAT_0/ 1
[ PAD_GPIO23]
[ PAD_MOD_TX_P00~ 07]
[
PAD_GPIO31SDA4]
[
PAD_GPIO24]
AGP_CTL
A
G
P
C
T
L
VX1_MSE
BIT [2:3] DISPLAY TYPE TYPE Data lane RGB/M+ COMMENT
[Level 0 : Level 0] LCD_UHD VBY1 N/A RGB/M+ V16_V17_V18 [Level 0 : Level 1]
[Level 0 : Level 2]
[Level 0 : Level 3]
[Level 1 : Level 0] LCD_UHD LGD_EPI_3G V18 6lane RGB
[Level 1 : Level 1] LCD_UHD LGD_EPI_3G V18 6lane M+ [Level 1 : Level 2] LCD_UHD LGD_EPI_3G V17 6lane M+ [Level 1 : Level 3]
[Level 2 : Level 0] LCD_UHD
BOE_CEDS_1.5
G
V18 12lane RGB
[Level 2 : Level 1] LCD_UHD
BOE_CEDS_1.5
G
17Y_18Y 12lane RGBW
[Level 2 : Level 2]
[Level 2 : Level 3]
[Level 3 : Level 0] LCD_UHD LGD_EPI_3G V18 8lane RGB
V18 8lane :
LGD 65UK75
65UK63
[Level 3 : Level 1] LCD_UHD LGD_EPI_3G V18 8lane M+
[Level 3 : Level 2] LCD_UHD
LGD_EPI_3G
Q- SAC
V18 6lane RGB
Q- SAC :
LGD 49inch
Only
[Level 3 : Level 3] LCD_UHD
LGD_EPI_3G
Q- SAC
V18 6lane M+
[ PAD_MOD_TX_P12(LVA3- )]
[
PAD_MOD_TX_N12(LVA3+)]
[
PAD_GPIO30SCK4]
[
PAD_GPIO19]
[
PAD_GPIO20]
Main IC
Main IC
IC
Main IC Main IC
Main IC
Main IC
Main IC
Main IC Main IC
Main IC
Main IC
