- 7 -

Only for training and service purposes.

5. External Input Support Format

5.1. Component (Y, PB, PR)

No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed

HDMI-PC

1 640*350 31.46 70.09 25.17 EGA

2 720*400 31.46 70.08 28.32 DOS

3 640*480 31.46 59.94 25.17 VESA(VGA)

4 800*600 37.87 60.31 40 VESA(SVGA)

5 1024*768 48.36 60.00 65 VESA(XGA)

6 1360*768 47.71 60.01 84.75 VESA(WXGA)

7 1152*864 54.34 60.05 80 VESA

8 1280*1024 63.98 60.02 109.00 SXGA Support to HDMI-PC

9 1920*1080 67.5 60 158.40 WUXGA

(Reduced Blanking)

10 1920*1080 135 120 297 UDTV 1080P

11 3840*2160 54 24.00 297.00 UDTV 2160P

12 3840*2160 56.25 25.00 297.00 UDTV 2160P

13 3840*2160 67.5 30.00 297.00 UDTV 2160P

14 4096*2160 53.95 23.97 296.70 UDTV 2160P

15 4096*2160 54 24 297 UDTV 2160P

No. Resolution H-freq(kHz) V-freq.(kHz) Pixel clock(MHz) Proposed

1 720*480i 15.73 59.94 13.50 SDTV, DVD 480I(525I)

2 720*480i 15.75 60.00 13.51 SDTV, DVD 480I(525I)

3 720*480p 31.47 59.94 27.00 SDTV 480P

4 720*480p 31.50 60.00 27.02 SDTV 480P

5 1280*720p 44.96 59.94 74.17 HDTV 720P

6 1280*720p 45.00 60.00 74.25 HDTV 720P

7 1920*1080i 33.72 59.94 74.17 HDTV 1080I

8 1920*1080i 33.75 60.00 74.25 HDTV 1080I

9 1920*1080p 67.43 59.94 148.5 HDTV 1080P

10 1920*1080p 67.50 60.00 148.5 HDTV 1080P

5.2. HDMI Input (PC/DTV)
