ENGLISH
15
HCEC Setup
CEC Mode
(Depending upon model)
• You will have 2 modes to choose [Default], [HCEC].
• If [Default] is selected, you can use SIMPLINK which is provided in LG Signage. Also you can enable and disable
SIMPLINK through SIMPLINK MENU.
IR Decoding
• When ‘IR Decoding’ is set to ‘Enable’, the Signage decodes and changes it into a CEC Message and sends it to
Command via the HDMI CEC Line. The default value is Disable.
Device ID
• Sets the ID of a device(Logical Address) connected to the CEC Line. You can choose ‘All’ and from ‘0 x 01’ to ‘0 x
0E’(All, 0 x 01 ~ 0 x 0e).
• The default value is ‘All’.
StandBy
• Set the sending and receiving scenario of OpStandBy(0 x 0c) command.
• This detailed scenario is described on the table below.
Send Receive
Send Only O X
Receive Only X O
All O O
O X X
