Communication Parameters
• Baud rate : 9600 bps (UART)
• Data length : 8 bits
• Parity : None
• Stop bit : 1 bit
• Communication code : ASCII code
• Use a crossed (reverse) cable.
Command reference list
(Depending upon model)
COMMAND1 COMMAND2 DATA (Hexadecimal)
1 Power k a 00 to 01
2 [Aspect Ratio] k c (page 30)
3 Screen Mute k d (page 30)
4 Volume Mute k e 00 to 01
5 Volume Control k f 00 to 64
6 [Contrast] k g 00 to 64
7 [Brightness] k h 00 to 64
8 [Color] k i 00 to 64
9 [Tint] k j 00 to 64
10
[Sharpness] k k 00 to 32
11
[OSD] Select k l 00 to 01
12
[Remote Control Lock Mode] k m 00 to 01
13
[Balance] k t 00 to 64
14
[Color Temperature] x u 00 to 64
15
[Equalizer] j v (page 32)
16
[Energy Saving] j q 00 to 05
17
Auto Conguration j u 01
18
Key m c Key Codes
19
Control Backlight m g 00 to 64
20
Input select x b (page 32)
• During playing media, all commands except Power (ka) and Key (mc) are not executed and treated as NG. With
RS232C cable, signage can communicate “ka command” in power-on or power-o status; but with USB-to-Serial
converter cable, the command works only if signage is on.
