2. PERFORMANCE
- 14 -
2.4 Current Consumption
1) KS20 Current Consumption
(Stand by and Voice Call Test Condition : Bluetooth off, LCD backlight off,Neighbor Cell off) (VT Test
Condition : Speaker off, LCD backlight On)
2) KS20 Current Consumption
(Stand by and Voice Call Test Condition : Bluetooth off, LCD backlight off,Neighbor Cell off) (VT Test
Condition : Speaker off, LCD backlight On)
2.5 RSSI BAR
Stand by Voice Call VT
WCDMA
Under 4.00 mA Under 600 mA Under 800mA
(DRX=1.28) (Tx=23dBm) (Tx=23dBm)
Under 3.00 mA Under 350 mA
GSM Paging=9 period (PCL=5)
Level Change WCDMA GSM
BAR 4 → 3 -82 ± 2 dBm -91 ± 2 dBm
BAR 3 → 2 -92 ± 2 dBm -96 ± 2 dBm
BAR 2 → 1 -102 ± 2 dBm -101 ± 2 dBm
BAR 1 → 0 -112 ± 2 dBm -106 ± 2 dBm
Stand by Voice Call VT
WCDMA
Under 2.5 mA Under 330 mA Under 500mA
(DRX=2.56) (Tx=10dBm) (Tx=10dBm)
Under 2.7 mA Under 270 mA
GSM
Paging=5 period (PCL=7)
