11. EXPLODED VIEW & REPLACEMENT PART LIST
- 191 -
11.2 Replacement Parts
<Mechanic component>
Note: This Chapter is used for reference, Part order
is ordered by SBOM standard on GCSC
Level
Location
No.
Description Part Number Spec Color Remark
1 GSM,BAR/FILP TGSM0048902
2 AAAY00 ADDITION AAAY0257802 Black
3 MLAZ00 LABEL MLAZ0037104 PRINTING, (empty), , , , , Metal Silver
4 MDAD00 DECO,CAMERA MDAD0028901 ELECTROFORMING, Cu, 0.2, , , , Silver
4 MPBZ00 PAD MPBZ0175301 COMPLEX, (empty), , , , , Black
4 MPBZ01 PAD MPBZ0175401 COMPLEX, (empty), , , , , Black
4 MTAB00 TAPE,PROTECTION MTAB0185501 COMPLEX, (empty), , , , , Transparent
4 MTAB01 TAPE,PROTECTION MTAB0185601 COMPLEX, (empty), , , , , Transparent
4 MTAZ00 TAPE MTAZ0184801 COMPLEX, (empty), , , , , Black
4 MTAZ01 TAPE MTAZ0191001 COMPLEX, (empty), , , , , Black
4 MTAZ02 TAPE MTAZ0191101 COMPLEX, (empty), , , , , Black
4 MWAE00 WINDOW,CAMERA MWAE0024201 CUTTING, PMMA MR 200, , , , , Black
4 MWAH00 WINDOW,FLASH MWAH0008501 MOLD, PC LUPOY GP-1000L, , , , , Milk
3 ACHA00 COVER SUB ASSY,FRONT ACHA0002502 Black
4 ACGK00 COVER ASSY,FRONT ACGK0101602 Silver
5 MBFF00 BRACKET,LCD MBFF0012401 MOLD, PA MXD6 RENY NXG5945S, , , , , Black
5 MBJC00 BUTTON,FUNCTION MBJC0021601 COMPLEX, (empty), , , , , Silver
5 MBJL00 BUTTON,SIDE MBJL0039001 COMPLEX, (empty), , , , , Silver
5 MBJN00 BUTTON,VOLUME MBJN0011801 COMPLEX, (empty), , , , , Silver
5 MBJP00 BUTTON,SHUTTER MBJP0006301 COMPLEX, (empty), , , , , Silver
5 MCCC00 CAP,EARPHONE JACK MCCC0043001 COMPLEX, (empty), , , , , Silver
5 MCCG00 CAP,MULTIMEDIA CARD MCCG0007501 COMPLEX, (empty), , , , , Silver
5 MCJK00 COVER,FRONT MCJK0068701 MOLD, PC LUPOY SC-1004A, , , , , Silver
5 MICA00 INSERT,FRONT MICA0019901 M1.4 D2.2 L1.5 Gold
5 MIDZ00 INSULATOR MIDZ0126601 COMPLEX, (empty), , , , , Green
5 MIDZ01 INSULATOR MIDZ0126801 COMPLEX, (empty), , , , , Green
5 MIDZ02 INSULATOR MIDZ0147601 COMPLEX, (empty), , , , , Green
5 MLAB00 LABEL,A/S MLAB0001102 C2000 USASV DIA 4.0 White
5 MLAR00 LABEL,WARNING MLAR0005301 COMPLEX, (empty), , , , , Yellow
5 MLEA00 LOCKER,BATTERY MLEA0037401 MOLD, PC LUPOY SC-1004A, , , , , Silver
5 MPBZ00 PAD MPBZ0190801 COMPLEX, (empty), , , , , Black
5 MSDC00 SPRING,LOCKER MSDC0009201 Black
5 MSIY00 SHAFT MSIY0001101 CUTTING, STS, , , , , Silver
