11. EXPLODED VIEW & REPLACEMENT PART LIST
- 193 -
Level
Location
No.
Description Part Number Spec Color Remark
4 SACY00 PCB ASSY,FLEXIBLE SACY0060901 MAIN FPCB Black
5 SACE00 PCB ASSY,FLEXIBLE,SMT SACE0055401 Black
6 SACC00
PCB ASSY,FLEXIBLE,SMT
BOTTOM
SACC0034501 Black
7 D101 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D102 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D108 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D109 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
6 SACD00
PCB ASSY,FLEXIBLE,SMT
TOP
SACD0045101
7 ANT100 ANTENNA,GSM,FIXED SNGF0022802
3.0 ,-2 dBd, ,WLAN, SMD, 8.0*3.0*1.5, RDL 8.5, ISCA-
D5 ,; ,SINGLE ,-2.0 ,50 ,3.0
7 CN100 MICROPHONE SUMY0010507 UNIT ,42 dB,4*1.35 ,SMD
7 CN101 CONNECTOR,FFC/FPC ENQY0008602 6 PIN,0.5 mm,ETC ,AU ,H:1.2MM
7 D103 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D104 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D105 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D106 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D107 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D110 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D111 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D112 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D113 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D114 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D115 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D116 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D117 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D118 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 D119 DIODE,TVS EDTY0008606 DFN-2 ,7.82 V,150 mW,R/TP ,PB-FREE
7 LD100 DIODE,LED,7-SEG EDLS0001102 7 ,3 DIGIT,R/TP ,R,G,B 1.6*1.6*0.4
7 LD101 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
7 LD102 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
7 LD103 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
7 LD104 DIODE,LED,CHIP EDLH0012501 Snow White ,1608 ,R/TP ,color concept
7 R100 RES,CHIP ERHY0003301 100 ohm,1/16W ,J ,1005 ,R/TP
11.2 Replacement Parts
<Main component>
Note: This Chapter is used for reference, Part order
is ordered by SBOM standard on GCSC
