2. PERFORMANCE
- 7 -
2.1 System Overview
2. PERFORMANCE
Item Specification
Shape GSM900/1800/1900 and WCDMA2100 - Bar type Handset
Size 99.8 X 58 X 12.9 mm
Weight Under 92.5g (with 1050mAh Battery)
Power 3.7 V normal, 1050 mAh Li-Polymer
Talk Time Over 100 min (WCDMA, Tx=-23 dBm, Voice)
(with 800mAh) Over 150 min (GSM, Tx=Level 5, Voice)
Standby Time Over 300 Hrs (WCDMA, DRX=1.28)
(with 800mAh) Over 400 Hrs (GSM, Paging period=9)
Antenna Internal type
LCD Main 2.8” 262K 240 X 320 pixel (TFT)
LCD Backlight White LED Back Light
Camera Auto Focus - 2.0 Mega pixel (CMOS) + VGA Video Call Camera
Vibrator Yes (Coin Type)
LED Indicator Yes
MIC Yes
Receiver Yes
Earphone Jack Yes (18 pin)
Connectivity Bluetooth, USB
Volume Key Push Type(+, -)
External Memory Yes
I/O Connect 18 Pin
