- 132 -
4. TROUBLE SHOOTING
4.21 Headset microphone
HS MIC (18 pin Connector) → C105 → MIC2P(MSM7200)
LGE Internal Use Only
Copyright © 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
Start
nEAR_DET
(C312) is 0V?
Yes
END
Make a call
Change the MAIN board
VMIC_BIAS2 is biased
by 2.6V? (R301)
END
Yes
OK
NO
NO
NO
Change the headset and retry
YES
Change MAIN board
Sine wave appears at
C105 ?
Change the headset or
Main board and retry.
NO
Yes
