LGE Internal Use Only
Copyright © 2007 LG Electronics. Inc. All right reserved.
Only for training and service purposes
4. TROUBLE SHOOTING
- 130 -
4.20 Main microphone
MIC (OSF213-42DC) → CN602 → CN400 → C106 → MIC1P(MSM7200)
Start
VMIC_BIAS(R102)
is 2.6V
Change main board
NO
Make a call
Change the MIC
NO
YES
Change the Main board
Make sound to MIC
Work well?
END
YES
NO
YES
Sine wave appears at
C106?
