5. DOWNLOAD
- 138 -
5.1.2.1 Connecting to PC
• Click on the Select Port and then Select Port window will be pop up. Check if state shows Enable
for the port to be connected for downloading images. Then click on the Connect button.
(The port number(COM7) shall be different from that of the port number in the snapshot.)
• The status Ready is displayed when the application is ready for downloading. While the images are
transmitted from PC to the handset, a progressive bar (Red box) indicating the degree of
transmission of data is displayed.
