LG WT4801CW Service Manual

31
Yes
No
UNBALANCE ERROR
Is displayed?
Put laundry evenly
In the DRUM
assembly
Does the laundry lean toward
one side, not evenly put in the
DRUM assembly?
Is the washing machine
installed at an angle?
Yes
Yes
Does the inlet valve work
when the power is not
applied?
Replace the
INLET VALVE ASSEMBLY
No
Adjust the height of
washing machine
to be kept
horizontally
Yes
If the inlet
valve work
continuously
when the power
is applied,
Replace the MAIN
PCB ASSEMBLY
OVER FLOW ERROR
Yes
Is displayed?
Check the AIR
CHAMBER
and the tube
(clogged).
Yes
When you press both SOAK
button and Spin Speed button
simultaneously, is the water
level frequency over 21.0kHz?
No

LG WT4801CW Specifications

General

Electrical	120VAC@60Hz
Rating of Fuse	125V, 12A for 100~127V/60Hz
Auto Power Off	Yes
Inner Tub	Stainless
Softener Dispenser	Yes
Detergent Dispenser	Yes
Bleach Inlet	Yes
Inlet Water Pressure	14.5 ~ 116 PSI (100 ~ 800 kPa)
Time Delay	1-24 Hr
Spin Speed	Max. spin speed 1, 000
Cycles	Cotton/Normal, Heavy Duty, Bulky/Bedding, Tub Clean, Perm Press Casual, Delicates, Speed Wash, Rinse+Spin
Smart Rinse™with Jet Spray	Yes
Lid Interlock Switch	Magnet Sensor
Child Lock	Yes

Weight and Dimensions

Weight	145.5 lbs (58kg)
