LG WT4801CW Service Manual

2-2. CONNECTING WATER SUPPLY HOSE
6
WARNING:
1
Attach the water supply hose to the tap.
Push the water supply hose up so that the rubber packing
within the hose can adhere completely to the tap.
2
Connect the water supply hose to the tap.
Connect the water supply hose to the tap and then tighten it by
screwing it to the right.
3
Check water leakage.
After connecting the hose, open the tap to check for
any water leakage.
Connecting Water Supply Hose to the machine
• Connect the water supply hose to inlet valve of
the washing machine, and then lock it by turning
the hose connecting part.
• Check to see if there is a rubber seal inside the
connector.
• A nwe washing machine should be instailed with new
hoses. The old hoses shuld not be reused.
Accessories shown below are not included in this model, but are required
for the proper operation.
• Hot and Cold Water Hoses
• Tie Strap (for securing drain hose)
Screw Type
Water tap
Rubber Seal
Water Supply Hose
Hot
Cold
Water Hose
(to water inlet
on washer)
Rubber Seal
Water Hose
(to tap)
Rubber Seal
Before connecting the Water Supply Hose to the water tap, check the hose type and then choose the
correct instruction here under.

LG WT4801CW Specifications

General

Electrical	120VAC@60Hz
Rating of Fuse	125V, 12A for 100~127V/60Hz
Auto Power Off	Yes
Inner Tub	Stainless
Softener Dispenser	Yes
Detergent Dispenser	Yes
Bleach Inlet	Yes
Inlet Water Pressure	14.5 ~ 116 PSI (100 ~ 800 kPa)
Time Delay	1-24 Hr
Spin Speed	Max. spin speed 1, 000
Cycles	Cotton/Normal, Heavy Duty, Bulky/Bedding, Tub Clean, Perm Press Casual, Delicates, Speed Wash, Rinse+Spin
Smart Rinse™with Jet Spray	Yes
Lid Interlock Switch	Magnet Sensor
Child Lock	Yes

Weight and Dimensions

Weight	145.5 lbs (58kg)
