Lightware UMX-TP-TX100R User Manual

UMX-TP-TX100R
Programmer’s Reference Manual
Section 4. Programmers reference Page 33 / 43
4.8.8. Query analog color properties
Description: Check analog color properties data of the input ports.
Format
Example
Command
{:PICTURE#<in>@<S/A>I=?}
→
{:picture#2@si=?}
Response
(PICTURE#<in>@<S/A>I=
<DF_CHA>;<DF_CHB>;<DF_CHC>;
<G_CHA>;<G_CHB>;<G_CHC>;
<O_CHA>;<O_CHB>;<O_CHC>;
<CONT>;<SAT>;<BRIGHT>;<HUE>;)CrLf
←
(PICTURE#2@SI=
1023;1023;1023;
1023;1023;1023;
1023;1023;1023;
128;128;0;0;)CrLf
Legend: Please read section 4.8.6 on page 32.
4.8.9. Reset analog color properties
Description: Reset analog color properties of the input ports.
Format
Example
Command
{:PICTURE#<in>@<S/A>I=FACTORY}
→
{:picture#2@si=factory}
Response
(P SAVED)CrLf
(PICTURE#<in>@<S/A>I=
<DF_CHA>;<DF_CHB>;<DF_CHC>;
<G_CHA>;<G_CHB>;<G_CHC>;
<O_CHA>;<O_CHB>;<O_CHC>;
<CONT>;<SAT>;<BRIGHT>;<HUE>;)CrLf
←
←
(P SAVED)CrLf
(PICTURE#2@SI=
1023;1023;1023;
1023;1023;1023;
1023;1023;1023;
128;128;0;0;)CrLf
Legend: Please read section 4.8.6 on page 32.
4.8.10. Set analog input audio parameters
Description: This command changes the setup of the ADC on the audio board.
Format
Example
Command
{:AUDIN#<in>@<S/A>I=<VOL>;
<BAL>;<GAIN>;<PHS>;<DCF>}
→
{:audin#2@si=0;50;0;0;0;}
Response
(:AUDIN#<in>@<S/A>I=<VOL>;
<BAL>;<GAIN>;<PHS>;<DCF>)CrLf
←
(AUDIN#2@SI=0;50;0;0;0;)CrLf
Legend: <S/A>: Affected ports:
S = single selected output
A = all outputs
<VOL>: Volume: (default 0}
0, 100, 200, .. , 6200, 6300
where 0 = 0 dB, 6300 = - 63 dB
<BAL>: Balance: (default 50)
0 .. 100 %
<GAIN>: Gain: (default 0)
0, 3, 6, .. , 21, 24 dB
<POL>: Polarity inversion: (default 0)
0 = Normal (phase=0°),
1= Inverted (phase=180°)
<DCF>: Audio DC filter: (default 0)
0 = DC filter off,
1 = DC filter on.
