17
Power Supply
Mains Power
• This unit operates with a DC 9V 1.5A mains adapter (included).
• Connecting the unit to any other power source may cause damage to the unit. Unwind
the mains adapter to its full length. Connect the mains adapter to the DC IN Socket on
the right side of the unit and then to a mains socket. Make sure the mains adapter is
fully inserted into the mains socket. The unit is now connected and ready to use.
• To switch the unit o completely, withdraw the mains adapter from the mains socket.
SD / MMC AV OUT COAXIAL
DC IN 9-12V
ON OFF
DVD Player Right Side
To DC IN
9V-12V Socket
To the Mains
Socket
• Turn o the unit before unplugging the mains adapter from the unit to avoid
the unit being damaged.
• When the unit is not going to be used for a long period of time, disconnect
the mains adapter from the mains socket.
• The mains socket must be located near the unit and should be easily
accessible. If a malfunction occurs, disconnect the plug from the mains socket
at once.
• When the mains adapter is plugged in, the unit is not completely
disconnected from the mains power source, even when the unit is turned o.
L10SPDV13_IB_161013_will.indd 17 13/10/2016 10:09 AM
