Manitowoc Grove 5540F Service Manual

11-57
5540F/YB5515 SERVICE MANUAL STRUCTURALS
11
13. Using a suitable puller, remove bearing cone 15 from
pinion shaft 1. Remove spacer 16.
14. Using a suitable puller, remove worm gear 17from pinion
shaft 1. Remove spacer 16.
15. Using a suitable puller, remove bearing cone 15 from
pinion shaft 1.
16. Remove pinion shaft 1 and worm 26 from housing 25.
17. Remove wiper seal 3 from housing 25.
Reference Only
