2013 MasterCraft Owners Manual • Electronic Instrumentation • Page 3-21
Display Selector Switch
(ProStar 190, ProStar 197)
On the models equipped with multi-function in the Tachometer
gauge, this switch allows the operator to
toggle between functions.
Heater Switch
(Optional Installation for All Models)
Among the accessory options available for your boat is a
heater function. The heater’s three-position switch is turned
upforON(LOW),orturneddownforON(HIGH).Thecenter
position is OFF. Warmed air from an electrically powered
heater box will be blown from vents within the boat deck.
Seat Heat Switches
(Optional All Models for Driver’s Seat; Certain Models for Observer’s
Seat)
A two-position switch allows heat to be turned ON for the driver’s
seat. In some models, an optional observer seat heat switch is avail-
able and will be found on the deck below the observer seat cushion.
Note that this switch will operate only when the ignition is in the ON
position.
Shower Switch
(Optional Installations on Most Models)
A combination switch is mounted in an aft position (transom
or storage area) controls the optional shower function. The
switch is marked. Press up on the switch to turn ON (a green
LED light will be lighted when the shower is operating). Press
down to turn OFF.
Tower Lights Switch
(Optional Installation for All Models)
The location of the aft light switch (where equipped) will
vary by model and should be located by the operator. In
some instances, there may be two (2) switches. In all in-
stances, the lights operate by using two-position switches,
one position for ON and the other for OFF.
Underwater Lights Switch
(All Models)
A combination switch is mounted in an aft position (transom or
storage area) controls the optional underwater lights function
or the lower throttle panel. The switch is marked. Press up on
the switch to turn ON (a green LED light will be lighted when the
shower is operating). Press down to turn OFF.
