An auxiliary heat exchanger is connected to the water circuit in parallel with the front-end
heat exchanger. The heat exchanger is installed under the floor behind the B-pillar, on the
left-hand side of the vehicle. The control panel, with controls for temperature and air
volume, is situated in the instrument panel. The warm air is routed upwards through the
floor panel and enters the load compartment/passenger compartment via a duct bolted
to the wood floor.
H13 requires HZ9, H12, HZ5 and H13 is not available in combination with T19
The auxiliary heat exchanger can only be switched on when the engine is running
Provides warm air flow for rear passenger compartment
Improved effectiveness when heating the load/passenger compartment when the engine
is switched on
