Sprinter 906

L72

Electrical Pre-installation for Load Compartment Lighting

Details & Technology

Instrument panel switch and wiring to rear cross-member. (Chassis Cab) .The interface

supports bulb loads up to a maximum of 4 Amps and ohmic loads up to a maximum of 10

Amps.

Benefits & Arguments

•

Simplifies retrofitting of load compartment lighting

Allows body manufacturers to install cargo compartment lights quick and easy.

Available for Chassis Cab.
