PRO6 Control Centre
Quick Reference Guide
Appendix A: Troubleshooting
This chapter gives a brief troubleshooting guide to the PRO6 Control Centre.
No audio
If you have set up the PRO6 and followed all of the instructions for obtaining audio, but
you are not hearing anything through the speakers, check the following:
• Make sure the appropriate ST buttons in the channel fast strips are on.
• Make sure the appropriate ST buttons in the source a/b panels (monitors section of
the master bay) are on.
• Make sure nothing is muted.
• Make sure no faders are set to minimum.
• Check that the VCA/group master faders are at unity gain.
• Use solo at selected points in the signal path to try and pinpoint where the signal is
being lost.
• Check for correct signal routing by making sure channel sources/destinations are
correctly assigned.
If you still don’t have any audio, contact Midas Technical Support.
Diagnostics
During operation you can view the Diagnostics screen (see Figure 16 below) to get an
overview of the current health and status of the system. The screen shows real-time
connectivity of the system and the health of connected nodes. In general, green items
are healthy and red ones indicate a problem. The Diagnostics screen also includes a
Swap button for changing the current network from X to Y, and vice versa. For more
information, see the PRO6 Control System Owner’s Manual.
Figure 16: Diagnostics screen
