The cooker hood works with
. . . air extraction:
The air is drawn in, cleaned by the
grease filter and then directed outside.
If the on-site ventilation system does
not have a non-return flap, then the
non-return flap supplied with the
appliance must be fitted in the exhaust
socket in the motor unit.
Having a non-return flap fitted in the
ducting ensures that air, once ducted
to the outside, cannot get back into the
room again.
The flap is closed when the cooker
hood is switched off.
When the cooker hood is switched on,
the non-return flap opens for the
cooking vapours to be blown directly
outside.
. . . air recirculation:
(air recirculation conversion kit
required)
The air is drawn in and cleaned first by
the grease filter and then by a charcoal
filter. The cleaned air is then
recirculated back into the kitchen.
Charcoal filters are available to order
through your Dealer / Chartered Agent
or the Miele Spare Parts Department or
via the internet at www.miele-shop.com.
(See back cover for contact details and
"Technical Data" for model number).
Before using the cooker hood in
recirculation mode, ensure that the
charcoal filter is in place; see
"Cleaning and care".
Description of the functions
12

Miele DA 3360 Specifications

General

Type	Built-in
Cord length	1.5 m
Product color	Stainless steel
Built-in display	-
Exhaust connection diameter	150 mm
Built-in capability	Yes
Installation compartment dimensions (WxDxH)	595 x 275 x 414 mm
Intensive speed	No
Number of speeds	3
Type of extraction	Ducted/Recirculating
Maximum extraction power	320 m³/h
Maximum recirculating power	200 m³/h
Minimum distance from gas hob	650 mm
Noise level (recirculation mode)	67 dB
Minimum distance from electric hob	450 mm
Current	10 A
AC input voltage	230 V
Power consumption (typical)	210 W
Number of filters	1 pc(s)
Bulb type	Halogen
Bulb power	50 W
Number of bulbs	2 bulb(s)

Weight and Dimensions

Depth	275 mm
Width	595 mm
Height	414 mm
Weight	12000 g
