Changing a halogen lamp
^
Pull out the deflector plate, and
remove the grease filter as described
earlier.
^
Switch off the fan and the lighting.
,
Exercise caution when changing
halogen lamps. They get very hot
during use, and remain hot for some
time after being switched off. Do not
touch the surface directly when
changing a lamp, as grease
particles from your fingers will
adhere to the surface and damage
it. Please follow the manufacturer’s
instructions.
^ Remove the charcoal filter if the
cooker hood is being used in
recirculation mode.
Before any cleaning or maintenance
work, disconnect the cooker hood
from the mains supply.
^ Push down the lighting unit slightly
via the opening in the safety panel.
^ The halogen lamp is now accessible
to be unscrewed anti-clockwise.
^ Replace it with a new halogen lamp
(specification: GU/GZ 10, 230 V,
50 W). Screw the lamp into the
socket and push it upwards.
Please follow the manufacturer's
instructions.
^
Replace the grease filter and, if being
used in recirculation mode, the
charcoal filter.
Cleaning and care
17

Miele DA 3360 Specifications

General

Type	Built-in
Cord length	1.5 m
Product color	Stainless steel
Built-in display	-
Exhaust connection diameter	150 mm
Built-in capability	Yes
Installation compartment dimensions (WxDxH)	595 x 275 x 414 mm
Intensive speed	No
Number of speeds	3
Type of extraction	Ducted/Recirculating
Maximum extraction power	320 m³/h
Maximum recirculating power	200 m³/h
Minimum distance from gas hob	650 mm
Noise level (recirculation mode)	67 dB
Minimum distance from electric hob	450 mm
Current	10 A
AC input voltage	230 V
Power consumption (typical)	210 W
Number of filters	1 pc(s)
Bulb type	Halogen
Bulb power	50 W
Number of bulbs	2 bulb(s)

Weight and Dimensions

Depth	275 mm
Width	595 mm
Height	414 mm
Weight	12000 g
