Miele DA 3360 User Manual

Setting up for recirculation
mode
If site conditions are not suitable for the
cooker hood to be used with air
extraction, the appliance must be set
up for recirculation.
For this, conversion kit DUU 151
(available from your Miele dealer or the
Miele Spare Parts Department) is
required.
You will also need a charcoal filter (see
“Technical data”).
^
Fit the conversion kit as described in
the installation instructions supplied
with the kit.
^
Make sure that the slats in the
exhaust grille point towards the
centre of the room and not towards a
wall or the ceiling.
A non-return flap is not used in
recirculation mode.
^
Fit the charcoal filter (see “Cleaning
and care”).
Electrical connection
Refer to the notes in “Electrical
connection” and “Warning and
Safety instructions” before
connecting to the electricity supply.
^ Connect the appliance to the
electricity supply.
Installation
29

Miele DA 3360 Specifications

General

Type	Built-in
Cord length	1.5 m
Product color	Stainless steel
Built-in display	-
Exhaust connection diameter	150 mm
Built-in capability	Yes
Installation compartment dimensions (WxDxH)	595 x 275 x 414 mm
Intensive speed	No
Number of speeds	3
Type of extraction	Ducted/Recirculating
Maximum extraction power	320 m³/h
Maximum recirculating power	200 m³/h
Minimum distance from gas hob	650 mm
Noise level (recirculation mode)	67 dB
Minimum distance from electric hob	450 mm
Current	10 A
AC input voltage	230 V
Power consumption (typical)	210 W
Number of filters	1 pc(s)
Bulb type	Halogen
Bulb power	50 W
Number of bulbs	2 bulb(s)

Weight and Dimensions

Depth	275 mm
Width	595 mm
Height	414 mm
Weight	12000 g
