Miele DA 3360 User Manual

1) The front section of the wall housing
unit must be fitted with a shelf to the
depth of the partition wall.
If the appliance is fitted further back,
e.g. to accomodate a front panel, then
the shelf depth should be
correspondingly deeper.
2) The partition wall in the wall unit must
be removable.
3) In extraction mode: when measuring
for the height of the wall housing unit
and the cut-out, account must be taken
of any accessories fitted, e.g. a
silencer.
4) Recirculation mode requires
installation kit DUU 151.
Safety distance between hob and
cooker hood
The following distance must be
maintained between the top of the
cooker/hob and the bottom of the
cooker hood unless a greater
distance is specified by the
manufacturer of the cooker or hob:
above electric hobs and cookers
450 mm
above electric barbecue grilles and
deep fat fryers 650 mm
above gas hobs and cookers
650 mm
If this cooker hood is installed above
a Miele Wok CS 1028 CombiSet
appliance, a minimum safety
distance of 760 mm must be
maintained between the burner and
the lower edge of the cooker hood.
See “Warning and Safety
instructions” for further information.
Appliance dimensions
19

Miele DA 3360 Specifications

General

Type	Built-in
Cord length	1.5 m
Product color	Stainless steel
Built-in display	-
Exhaust connection diameter	150 mm
Built-in capability	Yes
Installation compartment dimensions (WxDxH)	595 x 275 x 414 mm
Intensive speed	No
Number of speeds	3
Type of extraction	Ducted/Recirculating
Maximum extraction power	320 m³/h
Maximum recirculating power	200 m³/h
Minimum distance from gas hob	650 mm
Noise level (recirculation mode)	67 dB
Minimum distance from electric hob	450 mm
Current	10 A
AC input voltage	230 V
Power consumption (typical)	210 W
Number of filters	1 pc(s)
Bulb type	Halogen
Bulb power	50 W
Number of bulbs	2 bulb(s)

Weight and Dimensions

Depth	275 mm
Width	595 mm
Height	414 mm
Weight	12000 g
