Page #13 background imageLoading...
Page #13 background image
,
Before any cleaning or
maintenance work is carried out,
disconnect the cooker hood from the
mains supply.
,
Exercise caution when changing
halogen lamps. They get very hot
during use and remain hot for some
time after being switched off. The
hot lamps are also susceptible to
damage from damp cleaning. Wait a
few minutes after switching off
before commencing cleaning.
Housing
General
The surfaces and controls are
susceptible to scratches and
abrasion. Please observe the
following cleaning instructions.
^
All external surfaces and controls can
be cleaned using a Miele E-Cloth or
with warm water and a little
washing-up liquid applied with a well
wrung-out soft sponge or cloth.
^
Wipe the surfaces dry using a soft
cloth.
Do not use too much water when
cleaning the controls. Water could
penetrate into the electronics and
cause damage.
Avoid:
cleaning agents containing soda,
acids, chlorides or solvents,
abrasive cleaning agents, e.g.
powder cleaners or cream cleaners
and abrasive sponges, as well as pot
scourers or sponges which have
been used previously with abrasive
cleaning agents. These will damage
the surface material.
Important for appliances with
stainless steel housing
(This infomation does not apply to the
controls).
Stainless steel surfaces can be cleaned
using the Miele E-Cloth or with a
suitable, non-abrasive, proprietary
cleaning agent for stainless steel,
following the manufacturer's
instructions on the packaging.
To help prevent re-soiling, Miele
conditioning agent for stainless steel
can also be used. Follow the
instructions on the packaging.
Cleaning and care
13

Other manuals for Miele DA 3360

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Miele DA 3360 and is the answer not in the manual?

Miele DA 3360 Specifications

General IconGeneral
TypeBuilt-in
Cord length1.5 m
Product colorStainless steel
Built-in display-
Exhaust connection diameter150 mm
Built-in capabilityYes
Installation compartment dimensions (WxDxH)595 x 275 x 414 mm
Intensive speedNo
Number of speeds3
Type of extractionDucted/Recirculating
Maximum extraction power320 m³/h
Maximum recirculating power200 m³/h
Minimum distance from gas hob650 mm
Noise level (recirculation mode)67 dB
Minimum distance from electric hob450 mm
Current10 A
AC input voltage230 V
Power consumption (typical)210 W
Number of filters1 pc(s)
Bulb typeHalogen
Bulb power50 W
Number of bulbs2 bulb(s)
Weight and Dimensions IconWeight and Dimensions
Depth275 mm
Width595 mm
Height414 mm
Weight12000 g
