Miele G 7200 SCi User Manual

Loading the dishwasher
42
Adjusting the upper basket
In order to gain more space for taller
pieces of crockery in the lower basket
or upper basket, the upper basket can
be adjusted on 3levels with 2cm
between each level.
The upper basket can also be set at an
angle so that water can run off freely
from recesses. Make sure, however,
that the basket can slide smoothly in
and out of the wash cabinet.
 Pull out the upper basket.
To raise the upper basket:
 Lift the basket up until it clicks into
place.
To lower the upper basket:
 Pull upwards on the levers at either
side of the upper basket.
 Adjust the basket to the desired
height and then push the levers se-
curely back down into position.
When adjusting the upper basket,
make sure that tall plates in the lower
basket do not block the middle spray
arm.

Miele G 7200 SCi Specifications

General

Door color	Not applicable
Water fill	Cold, Hot
Cord length	1.7 m
Control type	Buttons
Product size	Full size (60 cm)
Inlet hose length	1.5 m
Custom panel-ready	Yes
Appliance placement	Semi built-in
Control panel color	Black
Cutlery compartment type	Drawer
Cycle time	230 min
Noise level	43 dB
Drying system	Condensation
AquaStop function	-
Delay start (max)	24 h
Dishwashing programs	Auto, Eco, Express, Glass/delicate, Intensive 75°C, Quick, Silent
Number of place settings	14 place settings
Number of washing programs	8
Maximum hot water supply temperature	60 °C
Current	10 A
Connected load	2000 W
AC input voltage	230 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	8.4 L

Weight and Dimensions

Depth	570 mm
Width	598 mm
Height	805 mm
Weight	47200 g
Depth with door open	1165 mm
Custom panel weight (max)	10000 g
Custom panel weight (min)	3000 g
Installation compartment width	600 mm
Installation compartment height (max)	870 mm
