Miele H6560BP User Manual

,
Danger of injury.
All electrical work should be
undertaken by a suitably qualified
and competent person.
Installation, repairs and other work
by unqualified persons could be
dangerous. Miele cannot be held
liable for unauthorised work.
Ensure power is not supplied to the
appliance until after installation or
repair work has been carried out.
Connection of this appliance to the
electricity supply must be made in
accordance with current safety
regulations (BS 7671 in the UK).
Connection of this appliance should be
made via a fused connection unit or a
suitable isolator and the on/off switch
should be easily accessible after the
appliance has been built in.
If the switch is not accessible after
installation (depending on country) an
additional means of disconnection must
be provided for all poles.
When switched off there must be an
all-pole contact gap of 3 mm in the
isolator switch (including switch, fuses
and relays according to EN 60335).
Connection data
The required connection data are given
on the data plate located on the oven
trim visible when the door is open.
Ensure that these match the mains
supply.
When contacting Miele, please quote
the following:
–
Model number
–
Serial number
–
Connection data
(voltage/frequency/maximum
connected load)
When replacing the cable supplied
with another cable or changing the
connection, only cable type
H05VV-F with a suitable
cross-sectional area (CSA) may be
used (available from Miele Spare
Parts).
Electrical connection
133
Oven
This oven is supplied with an approx.
1.7 m long 3-core cable for connection
to a 230 V, 50 Hz supply.
The wires in the mains lead are
coloured as follows:
Green/yellow = earth;
Blue = neutral;
Brown = live
WARNING, THIS APPLIANCE MUST
BE EARTHED
For extra safety it is advisable to protect
the appliance with a suitable residual
current device (RCD).
Maximum connected load: see data
plate.

Miele H6560BP Specifications

General

Style	single
Color	stainless steel
Total Capacity	2.68 cu. ft.
Temperature Probe	yes
Convection	yes
Control Type	touch sensor
Interior Light	yes
Kitchen Timer	yes
Power Consumption	5400
Electrical Requirements	240/208v, 60hz, 20a
Voltage	240/208 volts
Current	20

Weight and Dimensions

Depth	22 3/8 inch
Height	23 7/16 inch
Width	23 7/16"
