Miele KF 1901 Vi User Manual

Further settings
Further settings can be selected in the
settings mode.
In settings mode, you can select certain
appliance functions via the control
panel and adjust the settings. The
settings for the different functions are
described in more detail in the relevant
section of these instructions.
Overview of functions that can be
selected in the settings mode:
Function Symbol
displaye
d
To enter or leave
settings mode
;
To select the
temperature unit (see "The
correct temperature")
†
No function selected ;
To switch the sensor tone
on/off (see "Switching on
and off")
=
No function selected ^
To switch the sensor tone on/off
The tone which sounds each time a
sensor is touched can be deactivated.
^
Touch the access sensor so that it is
highlighted in yellow.
^ Touch the sensor for the refrigerator
zone so that it is highlighted in
yellow.
^ Take note of the position of the X
sensor (but do not touch it!).
^ Touch the access sensor until it is
highlighted in white and all of the
other sensors are no longer lit up.
^ Place your finger in the position of the
X sensor, and leave it there.
^
At the same time, briefly touch the
access sensor (without letting go of
the X sensor).
Switching on and off
21

Miele KF 1901 Vi Specifications

General

Door hinge	Right
Product color	Stainless steel
Reversible doors	Yes
Door opening angle	115 °
Appliance placement	Built-in
Door panel included	No
Power requirements	230 V, 50 Hz
Fridge number of compressors	2
Noise level	40 dB
Total net capacity	483 L
Total gross capacity	- L
Fridge net capacity	313 L
Fridge number of shelves/baskets	3
Fresh zone compartment net capacity	71 L
Star rating	4*
Freezing capacity	20 kg/24h
Freezer net capacity	99 L
Storage time during power failure	17 h
Connected load	632 W
Annual energy consumption	365 kWh

Weight and Dimensions

Depth	610 mm
Width	902 mm
Height	2127 mm
Weight	201000 g
Installation compartment dimensions (WxDxH)	915 x 629 x 2134 mm
