Miele KF 1901 Vi User Manual

Moving the shelves
The shelves can be adjusted according
to the height of the food.
^
Hold the shelf on both sides and
raise it slightly so that it can be lifted
over the catches at the back.
^
Pull the shelf forwards.
^
Place the shelf at the required level,
ensuring that it has engaged in the
catches at the back.
^
Make sure that the shelf is on
straight.
Floating deli drawer
The drawer can be positioned to the
right or left by sliding it to the required
position.
It can also be placed, together with its
holder, under a different shelf - or this
can be achieved by simply swapping
the shelves over.
The floating drawer can be removed
completely for cleaning purposes:
^
To do this, pull the drawer out over
the drawer stops.
To replace it
^
Push the drawer straight into runners.
The MasterFresh drawer
The MasterFresh drawer sits on
telescopic runners, and can be fully
pulled out for loading and unloading.
For cleaning, the MasterFresh drawer
can be removed completely.
^ Pull the MasterFresh drawer out as
far it will go.
To prevent children from hurting
themselves, there is a pin on the door
opening side which needs to be turned
to a horizontal position in order to
remove the drawer.
^
Use a screwdriver or similar to turn
the pin so that the slot in its head is
horizontal a.
^
Raise the snap fittings on both sides
b, and lift the MasterFresh drawer
up and out.
Arranging the interior fittings
37

Miele KF 1901 Vi Specifications

General

Door hinge	Right
Product color	Stainless steel
Reversible doors	Yes
Door opening angle	115 °
Appliance placement	Built-in
Door panel included	No
Power requirements	230 V, 50 Hz
Fridge number of compressors	2
Noise level	40 dB
Total net capacity	483 L
Total gross capacity	- L
Fridge net capacity	313 L
Fridge number of shelves/baskets	3
Fresh zone compartment net capacity	71 L
Star rating	4*
Freezing capacity	20 kg/24h
Freezer net capacity	99 L
Storage time during power failure	17 h
Connected load	632 W
Annual energy consumption	365 kWh

Weight and Dimensions

Depth	610 mm
Width	902 mm
Height	2127 mm
Weight	201000 g
Installation compartment dimensions (WxDxH)	915 x 629 x 2134 mm
