Miele KF 1901 Vi User Manual

Aluminium frames
The frames on the shelves inside the
appliance and in the door are made
from aluminium.
Aluminium is affected by the way that
light falls on it, by the surrounding
environment and by the angle you
observe it from.
It is also susceptible to scratching.
The aluminium frames may suffer
discolouration or damage if soiling is
left on for too long. Remove any
soiling immediately.
Ice cube container
The ice cube container sits on
telescopic runners, and can be fully
extended for loading and unloading.
For cleaning, this drawer can be
removed completely.
^
Pull the ice cube container out as far
as it will go.
^ Raise the snap fittings on both sides
and lift the ice cube container out.
To avoid injury or damage to the
telescopic runners, make sure that
they are pushed back into the
appliance.
To replace the ice cube container:
^
Pull the telescopic rails out as far as
they will go.
^
Place the ice cube container on the
rails so that it engages at the back
and front.
^
Push the ice cube container back in.
Cleaning and care
49

Miele KF 1901 Vi Specifications

General

Door hinge	Right
Product color	Stainless steel
Reversible doors	Yes
Door opening angle	115 °
Appliance placement	Built-in
Door panel included	No
Power requirements	230 V, 50 Hz
Fridge number of compressors	2
Noise level	40 dB
Total net capacity	483 L
Total gross capacity	- L
Fridge net capacity	313 L
Fridge number of shelves/baskets	3
Fresh zone compartment net capacity	71 L
Star rating	4*
Freezing capacity	20 kg/24h
Freezer net capacity	99 L
Storage time during power failure	17 h
Connected load	632 W
Annual energy consumption	365 kWh

Weight and Dimensions

Depth	610 mm
Width	902 mm
Height	2127 mm
Weight	201000 g
Installation compartment dimensions (WxDxH)	915 x 629 x 2134 mm
