Miele KF 1901 Vi User Manual

Aligning the appliance
^
Align the appliance with
neighbouring furniture fronts.
The installation aids c on the
appliance door are suitable for a
thickness of 19 mm or 38 mm.
The adjustable feet at the front and
back of the appliance can all be
adjusted from the front:
–
Front feet:
Adjustment from above with a
socket wrench (attachment: nut,
8 mm) d.
–
Back feet:
Adjustment with a power drill or
socket wrench (attachment: nut,
8 mm) for fine adjustment e.
^
Place a spirit level across the
installation aids c on the appliance
door to check the appliance's
alignment.
Important!
Proceed carefully when adjusting
the feet, alternating between the left
and right feet.
^
A mark is located on the appliance
base. When adjusting the height, this
mark needs to be aligned at 32 mm
from the floor. Unscrew the feet until
the mark on the base has reached 32
mm. This measurement of 32 mm
corresponds to a building-in recess
height of 2134 mm.
Important!
Unscrew the feet until the mark is
aligned to a maximum of 62 mm
from the floor (max. building-in
recess of 2164 mm).
Otherwise the rear feet alignment
will be damaged.
^
Check the alignment of the appliance
again using the spirit level.
Installation
84

Miele KF 1901 Vi Specifications

General

Door hinge	Right
Product color	Stainless steel
Reversible doors	Yes
Door opening angle	115 °
Appliance placement	Built-in
Door panel included	No
Power requirements	230 V, 50 Hz
Fridge number of compressors	2
Noise level	40 dB
Total net capacity	483 L
Total gross capacity	- L
Fridge net capacity	313 L
Fridge number of shelves/baskets	3
Fresh zone compartment net capacity	71 L
Star rating	4*
Freezing capacity	20 kg/24h
Freezer net capacity	99 L
Storage time during power failure	17 h
Connected load	632 W
Annual energy consumption	365 kWh

Weight and Dimensions

Depth	610 mm
Width	902 mm
Height	2127 mm
Weight	201000 g
Installation compartment dimensions (WxDxH)	915 x 629 x 2134 mm
