Miele KF 1901 Vi User Manual

^
Do not remove the installation aids
from the appliance doors. These will
be required later when the appliance
is installed in the building-in niche.
^
Check the appliance for damage
during transportation.
Do not install a damaged appliance!
^
Unscrew the bracket that is holding
the appliance to the delivery pallet.
,
Warning!
Please bear in mind that the
appliance is no longer secured to the
pallet!
^
With the help of several people as
required, carefully lift the appliance
from the pallet, starting with the back
of the appliance.
The appliance can be rolled along the
floor using the wheels at the back.
Preparing the niche
,
Keep the door and drawer to the
appliance closed until it is fixed
inside the building-in niche.
Due to the sheer size and weight of
the appliance, it needs to be
ensured that it cannot tip forwards
once it is built into the niche.
Assembly parts
All the fixings required for installation
are supplied with the appliance. The
plastic bags are marked with letters for
easy identification.
Each fitting stage is indicated by the
letter on the bag needed for that stage.
Installation
80

Miele KF 1901 Vi Specifications

General

Door hinge	Right
Product color	Stainless steel
Reversible doors	Yes
Door opening angle	115 °
Appliance placement	Built-in
Door panel included	No
Power requirements	230 V, 50 Hz
Fridge number of compressors	2
Noise level	40 dB
Total net capacity	483 L
Total gross capacity	- L
Fridge net capacity	313 L
Fridge number of shelves/baskets	3
Fresh zone compartment net capacity	71 L
Star rating	4*
Freezing capacity	20 kg/24h
Freezer net capacity	99 L
Storage time during power failure	17 h
Connected load	632 W
Annual energy consumption	365 kWh

Weight and Dimensions

Depth	610 mm
Width	902 mm
Height	2127 mm
Weight	201000 g
Installation compartment dimensions (WxDxH)	915 x 629 x 2134 mm
