Miele KF 1901 Vi User Manual

Fitting the stainless steel hose
to the appliance
When fitting the stainless steel hose,
make sure that it is neither kinked
nor damaged.
^ Remove the cap (1.) from the water
connection at the front of the
appliance.
^ Screw the stainless steel hose
coupling nut (2.) onto the threaded
union (3.).
^
Ensure that all connections are water
tight.
^
Turn on the tap slowly and check the
whole water system for leaks.
^
The appliance can then be
connected to the electricity supply
(see "Electrical connection").
After a maximum of 10 hours, the first
ice cubes will drop out of the ice
cube maker and collect in the
container.
Mains water connection
66

Miele KF 1901 Vi Specifications

General

Door hinge	Right
Product color	Stainless steel
Reversible doors	Yes
Door opening angle	115 °
Appliance placement	Built-in
Door panel included	No
Power requirements	230 V, 50 Hz
Fridge number of compressors	2
Noise level	40 dB
Total net capacity	483 L
Total gross capacity	- L
Fridge net capacity	313 L
Fridge number of shelves/baskets	3
Fresh zone compartment net capacity	71 L
Star rating	4*
Freezing capacity	20 kg/24h
Freezer net capacity	99 L
Storage time during power failure	17 h
Connected load	632 W
Annual energy consumption	365 kWh

Weight and Dimensions

Depth	610 mm
Width	902 mm
Height	2127 mm
Weight	201000 g
Installation compartment dimensions (WxDxH)	915 x 629 x 2134 mm
