Installation
*INSTALLATION*
59
Configuring the
room ventilation
opening
Rooms in which rotary irons and tumble dryers are operated
must have an induced ventilation system (e.g., ventilation slots in
windows and doors, wall openings with grilles, or opened windows
or skylights).
For example1
A duct diameter of 6"(150mm) was specified in example1. Accord-
ing to this duct diameter, a room ventilation opening with a size of
17'5"(531cm) is required. The edge length is 91/16"(230mm) (see
Table3).
For example2
A total duct diameter of 811/16"(220mm) was specified. According
to this duct diameter, a room ventilation opening with a size of
37'4"(1,140cm) is required. The edge length is 1413/16"(377mm)
(see Table3).
For example3
Since in this case the tumble dryer is connected to a central air sup-
ply, additional ventilation openings are not needed.
