Installation
*INSTALLATION*
62
 Before completing commissioning, maintenance, conversion,
and repair work, all gas-conducting components – from the manual
shut-off valve to the burner jet – must be checked for leaks.
Particular attention must be paid to the measuring stubs on the gas
valve. Checks must be performed when the burner is both switched
on and switched off.

Installing thermal shut-off equipment on site is recommended.

If gas-heated appliances are accessible to anyone, it is also neces-
sary to check whether a gas flow monitor needs to be used.
Gas supply
Required flow rate
Appliance type Rated heat load (Hi) Natural gas Liquid propane
PDR914/514
15kW
0.936CFM
(1.59m³/h)
2.6lb/h
(1.18kg/h)
PDR918/518
18kW
1.118CFM
(1.90m³/h)
3.13lb/h
(1.42kg/h)
PDR922/522 21.5kW
1.342CFM
(2.28m³/h)
3.75lb/h
(1.70kg/h)
PDR928/528 30kW
1.866CFM
(3.17m³/h)
5.22lb/h
(2.37kg/h)
PDR944/544 36kW
2.242CFM
(3.81m³/h)
6.26lb/h
(2.84kg/h)
The connected load is based on the following consumption calorific
values:
Natural gas: 913BTU/ft³ (34.02MJ/m³) (Hi))
Liquid propane: 19,625BTU/lb (45.65MJ/kg (Hi))
Natural gas
Natural
gas
Length of gas line
9'10"
(3m)
16' 47/8"
(5m)
32'
911/16"
(10m)
65' 73/8"
(20m)
98'5 1/8"
(30m)
164'1/2"
(50m)
328'1"
(100m)
Internal di-
ameter
Maximum flow rate
¾"
(20mm)
2.766CF
M
(4.7m³/h)
2.177CFM
(3.7m³/h)
1.53CFM
(2.6m³/h)
0.942CF
M
(1.6m³/h)
0.647CF
M
(1.1m³/h)
0.412CF
M
(0.7m³/h)
0.177CFM
(0.3m³/h)
1"
(25mm)
5.061CFM
(8.6m³/h)
4.061CF
M
(6.9m³/h)
2.825CF
M
(4.8m³/h)
1.824CFM
(3.1m³/h)
1.412CFM
(2.4m³/h)
1.118CFM
(1.9m³/h)
0.53CFM
(0.9m³/h)
1 ¼"
(32mm)
9.416CFM
(16.0m³/
h)
7.297CFM
(12.4m³/
h)
5.12CFM
(8.7m³/h)
3.649CF
M
(6.2m³/h)
2.942CF
M
(5.0m³/h)
2.236CF
M
(3.8m³/h)
1.412CFM
(2.4m³/h)
1 ½"
(40mm)
15.595CF
M
(26.5m³/
h)
12.064CF
M
(20.5m³/
h)
8.533CF
M
(14.5m³/
h)
6.062CF
M
(10.3m³/
h)
4.943CF
M
(8.4m³/h)
3.825CF
M
(6.5m³/h)
2.354CF
M
(4.0m³/h)
2"
(50mm)
35.31CFM
(60.0m³/
h)
27.66CFM
(47.0m³/
h)
19.421CF
M
(33.0m³/
h)
13.536CF
M
(23.0m³/
h)
11.181CFM
(19.0m³/
h)
8.828CF
M
(15.0m³/
h)
5.885CF
M
(10.0m³/
h)
