Pellerin Milnor Corporation 101
Table 34. Parts List—Cylinder Doors
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A SA 15 103 * CYLDOOR ASSY,STAMPED =42U
Components
all 1 02 15826 DOOR-CYLINDER-SS-DRAWN
all 2 02 15830 PLATE-CYLDOOR REINFORCING
all 3 02 15825 ADAPTER PLATE=DOOR LATCH
all 4 02 15832 SHIM=CYL DOOR LATCH
all 5 02 15077 PLATE = SMALL DOORLATCH
all 6 02 15041 BODY=CYLDOOR LATCH
all 7 02 15040 PLUNGER=CYLDOOR LATCH(CAST)
all 8 02 15093 SPRING=DOOR LATCH 9.4#/INCH
all 9 02 15255 LOCKWASHER CYLDOOR LATCH
all 10 02 15823 HALFHINGE-2/42"WEHU-302 SS
all 11 02 15829 PIN=HINGE 1/4"
all 12 15G168 SQNUT 1/4-20UNC2 SS18-8
all 13 15U181 LOCKWASHER MEDIUM 1/4 SS18-8
all 14 15K031 BUTSOKCAPSCR 1/4-20X1/2 SS18-8
all 15 15G170 HEXNUT 1/4-20UNC2 SS18-8
all 16 15N174 HXCAPSCR 1/4-20UNC X5/8SS18-8
all 17 15J008H BUTTON HD RIVET 3/16 X 1/2" SS
Cylinder Doors
2 Sheets
42031/42044 CP2,CP3,NP2,NP3,WP2,WP3,SP2,SP3,DA3; 4244WP2 SM,WP3 SM,
SP2 SM
Shell and Door Assemblies
To Next Page
