Pellerin Milnor Corporation 37

Table 19. Parts List—Drive Chart

Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this

letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.

Used In Item Part Number

Description/Nomenclature

Comments

Reference Assemblies

A D16 00561 DRIVE CHART=4244WE SINGLE MOTO

Components

all 1 02 16124 VPUL 5B20 (Q2) BRN PE-5008

all 2 56Q2DQ2S 2+3/16" SPLIT BUSHING BROWN Q2

all 3 56VB120X VBELT BX120 RAWEDGE COG

all 4 56080B5SF VPUL 5B8.0/A7.6 (SF) TYPE QD

all 5

56Q2HSF 2+7/16" BUSH VPUL QD TYPE SF

all 6 02 175121 KEY=5/8SQ

all 7 5607B110 PULLEY 7B11.0 TYPE E

all 8 56Q2AE 2.0" BUSHING VPUL QD TYPE "E"

all 9 02 15794 KEY-1/2X2+1/2 4231-4244SGH

all 10 56VB070XB3 VBAND 3RBX70 EACH=1

all 11 56070B6SF VPUL 6B7.0/A6.6 (SF) TYPE QD

all 12 56Q1RSF 1+7/8" BUSH VPUL QD TYPE SF

Drive Chart

2 Sheets

4244WP2 SM

Drive Assemblies
