28
Pellerin Milnor Corporation
NOTICE: Replace placard immediately, if removed or unreadable. Approximate loca-
tions of placards are shown. If aluminum placard, mounting holes are provided on machine.
Use #8 self-tapping screws.
Legend
A-A.Rear view
B—B.Left view
C-C.Front view
D-D.Right view
E...For steam pipe
Safety Placard Use and Placement
2 Sheets
42044WP2 & NP2 SINGLE MOTOR DRIVE
BPWD4M01 / 2020264
BPWD4M01.1 0000296185 A.3 A.4 6/24/20 10:57 AM Released
Safety-Related Components & Assemblies
