Pellerin Milnor Corporation 125
Table 42. Parts List—Steam Inlet
Find the assembly for your machine and the letter shown in the "Item" column. The components for your machine will show this
letter or the word "all" in the "Used In" column. The numbers shown in the "Item" column are those shown in the illustrations.
Used In Item Part Number
Description/Nomenclature
Comments
Reference Assemblies
A GVS15002 INSTALL=1.25STEAM 42WE2+3 REFERENCE
B AVS15001
$1.25 BURKERT STEAM=42WE2+3
REFERENCE
C AVS03001 *1+1/4BURKERT +STRAINER REFERENCE
D ASS25001 *52&60 STEAM SPARGER3/4ORFICE REFERENCE
Components
all 1 51T060 Y-STRAINER 1+1/4" CAST IRON
all 2 5SP0PHFSS NPT PLUG 3/4 SQ SOLID STL/ZINC
all 3 5N1E05AG42 NPT NIP 1.25X5 TBE GALSTL SK40
all 4 96D0011E 1.25"NPTBRZ N/C STEAMVALANGBD
all 5 96H018 ANGLE NEEDLE VLV 1/4"T X 1/8MP
all 6 5SB0E0CBEO NPTHEXBUSH 1/4X1/8 BRASS 125#
all 7
5N1E17AG42 NPT NIP 1.25X17 TBE GALSTL SK4
all 8 5SL1ENFA NPT ELB 90DEG 1.25 GALMAL 150#
all 9 5N1ECLSG42 NPT NIP 1.25XCLS TBE GALSTLS40
all 10 5SU1ENF NPT UNION 1.25" GALMAL 150#
all 11 51E096C MALESTEM 1.25"CADPL CAMP#IMS5
all 13 60E096C54A STEAMH*OSE=1.25"X54"+2ENDS=(NO
all 15 15G205 HXNUT 3/8-16UNC2B ZINC GR2
all 16 15U255 LOCKWASHER MEDIUM 3/8 ZINCPL
all 17 15G200 HXCPNUT 3/8-16 UNC2A 5/8X1/2
all 18 02 16306A BRKT=1+1/4"PIPE SUPPORT
all 19 15U240 FLATWASHER(USS STD) 3/8" ZNC P
all 20 27A032M UBOLT 2"PIPE 3/8-16 ZNC3.5" LG
all 21 27A035 UBOLT 3/8-16 3.625"BETWEN LEGS
all 23 5SL1ESFA NPT ELB 90DEG 1.25 304SS 150#
all 24 W3 64566B *WLM=STM SPARGER .75 ORF-12"L
all 25 02 14647E GASKET=DRNTRGH TO RECIRC BOX
all 26 W2 15897E *STEAM+WATER INLET WLDMT 42WE
all 27 27A084 HOSECLAMP 3+9/16-4.5CADSC#HS64
all 28 60E306A12A HOSE *3.5"ID GATES PE X12"
all 29 87Z070010A TUBE=3.5"OD X 10"LG SQ ENDS
all 30 60E306A18A HOSE= *3.5"ID PE X18"
Steam Inlet
4 Sheets
4244WR2/WR3
Water and Steam Piping and Assemblies
To Next Page
