21 - 4 Defibrillator/Monitor Operator’s Manual
21.6.3 AED Setup Menu
Charge Tone Vol High, Med, Low Med Sets the tone volume during the
charge, and when the charge is
completed.
This setting is also effective in
the AED mode.
Contact Impedance Indicator On, Off Off Sets whether to display the
contact impedance indicator.
Maximum Defib. Energy 360 J 360 J Sets the maximum energy level
for the delivered shock.
Menu Item Options/Range Default Description
Menu Item Options/Range Default Description
Shock Series 1, 2, 3 1 Sets the number of shocks. If it is
set to greater than one, the
equipment resumes analyzing
the patient’s rhythm after the
shock is delivered to determine
if the shock was successful.
Prompts for shock counter are
provided to guide you
delivering additional shocks.
Energy 1 (Adu) 100 J, 150 J, 170 J, 200 J, 300
J, 360 J
200 J Sets the defibrillation energy
level for the first shock on the
adult patient.
Energy 2 (Adu) Energy 1 to 360J 300 J Energy 1 ≤ configurable value ≤
Energy 3
Energy 3 (Adu) Energy 2 to 360J 360 J Energy 2 ≤ configurable value
Energy 1 (Ped) 10 J, 15 J, 20 J, 30 J, 50 J, 70 J,
100 J
50 J Sets the defibrillation energy
level for the first shock on the
pediatric patient.
Energy 2 (Ped) Energy 1 to 100 J 70 J Energy 1 ≤ configurable value ≤
Energy 3
Energy 3 (Ped) Energy 2 to 100 J 100 J Energy 2 ≤ configurable value
Time to Auto Disarm 30s, 60s, 90s, 120s 30s Sets the time the equipment
automatically removes the
stored energy internally.
CPR Mode (Adu) 30:2, 15:2, Compression only 30:2 Sets the rate of compression
and ventilation.
CPR Mode (Ped) 15:2
CPR Time 30 s, 60 s, 90 s, 120 s, 150 s,
180 s
120 s Sets the interval for the CPR
administration.
NSA Action Monitor, CPR CPR Sets what status the equipment
will enter.after “No Shock
Advised!” is given.
•[CPR]: the equipment enters
the CPR status.
•[Monitor]: the equipment
continues to monitor the
ECG and automatically
resumes analysis if a
potentially shockable
rhythm is detected.
Voice Prompts On, Off On Sets whether voice prompts are
provided in the AED mode.
