Mindray DC-70 Pro User Manual

Function and Performance Checking Method 5-11
Press <End Exam> during image scanning
 Press <Review> key.
 Click [Exit] on the Review screen; or, press
<Review> again, or, press <Esc> key
 The system enters into image review mode.
 The system exits image review mode.
 Click [iVision] on the other menu; or press
user-defined iVision key.
 Select the contents
to be demonstrated,
and select the demo mode in the iVision
screen. Then select an item already added
to the list and click [Start]

When the demonstration is finished, click
[Exit] or press <Esc>.
 Open iVision screen:
 Demonstration begins.
 Image files are
played according to file
names one by one (including the image of
system-relevant and PC-compatible format).
 The system exits the demonstration.
Press <iStation> key to enter patient information
management (iStation page)
The saved patient information (i
mages) can be
found, and the patient information can be:
 Backed up/ Restored

Sent (To DICOM or USB disk etc. )
5.5 Performance Test
5.5.1 Test Process
Resolution
Detection depth
Geometric Position
Accuracy
Blackout area test
Record the exam
images
5.5.2 Test Content
NOTE:
The image used here is only for reference, stick to the image effect in the real
situation.
Requirements:
1. Display: set the contrast and brightness at the clinical application value (or the default status)
2. Operation environment: dark room, simulating the clinical application environment.
