28.0 QMP-5101NV/N Network Paging Wiring
Figure 73 QMP-5101NV/N Network Master Paging Control Module Wiring to the
ANC-4000 Audio Network Controller Module
JW7
JW8
+ - + -
S - +
S - +
S - + S - + L - +
PAGING BUS
MIC
PTT
OUT
IN
ANC-4000 Audio Network
Controller Module
+
+
- -
S
PTT
MIC
Master microphone
and push to talk button
are wired by Factory to
these terminals
QMP-5101N/V Network
Master Paging Module
+
-
Remote
Power
Input
(24V DC
Regulated
1.7 A max)
FleX-Net
Fire Alarm
Aux. Power
Supply
G.A.
Input
IN
RS-485
NOT USED
Wire the Paging Bus
to all other ANC-4000
Audio Network
Controller Modules
OUT to IN.
TWISTED
SHIELDED
PAIR CABLE
Jumpers JW7 and JW8
are normally installed
(shorted).
This connection to Aux
Power is required when
the ANC-4000 is mount-
ed over an FX-4009-12N
Fire Alarm board.
