Mircom FleXNet FX-4000 User Manual

136
38.0 Appendix B: Power Supply and Battery Calculations
Battery Calculations continued. . . .
Power Requirements (All currents are in amperes)
Model Number Description Qty Standby
Total
Standby
Alarm
Total
Alarm
FX-4003-12N/12NXT
Main Chassis (12 Amp) X 0.310 = 0.733 =
FX-4017-12N Main Chassis (12 Amp) X 0.310 = 0.733 =
FX-4009-12N Large Main Chassis (12 Amp) X 0.310 = 0.733 =
ALCN-960MISO and
ALCN-960D
Quad Analog Loops X 0.200 = 0.230 =
ALCN-4792MISO
and ALCN-792D
Quad Analog Loops X 0.130 = 0.145 =
FNC-2000 Fire Network Controller Module X 0.190 = 0.190 =
ANC-4000 Audio Network Controller Module X 0.255 = 0.265 =
TNC-5000
Telephone Network Controller
Module
X 0.195 = 0.215 =
FOM-2000-UM Fiber Optics Module X 0.015 = 0.015 =
DM-1008A 8 Initiating Circuit Module X 0.080 =
1 zone active: 0.125
2 zone active: 0.170
4 zone active: 0.275
6 zone active: 0.370
8 zone active: 0.465
=
SGM-1004A 4 Indicating Circuit Module X 0.060 = 0.258 =
RM-1008A 8 Relay Circuit Module X 0.025 = 0.150 =
FDX-008W/WKI Fan Damper Control Module X 0.015 = 0.035 =
DSPL-420DS Narrow Display X 0.025 = 0.025 =
DSPL-2440 Graphic Display X 0.029 = 0.035 =
UDACT-300A Dialer Module X 0.045 = 0.120 =
PR-300 City Tie Module X 0.035 = 0.300 =
FDS-008 Selection Control Panel for MNS X 0.024 = 0.112 =
RAX-1048TZDS Adder Annunciator Chassis X 0.022 =
1 zone active: 0.026
2 zone active: 0.030
3 zone active: 0.035
4 zone active: 0.039
48 zone active: 0.262
=
RAM-1032TZDS Adder Annunciator Chassis X 0.050 = 32 zone active: 0.300 =
AGD-048 Adder Graphic Driver Board X 0.035 =
__(#of LEDs) x 4mA
(Refer to LT-847 if using
lamps)
=
IPS-4848DS/
IPS2424DS
Programmable Input Switches Module
X 0.010/0.005 = 0.022 =
Two-Wire Smoke Detectors X
♦
0.00005
=
*0.39
= 0.39
MIX-1251B/BA Analog Ion Smoke Detector X 0.0003 = 0.0065 =
MIX-2251B/BA Analog Photo Smoke Detector X 0.0003 = 0.0065 =
MIX-2251TMB/TMBA Analog Thermal Sensor X 0.0003 = 0.0065 =
MIX-M500MB/MA, MIX-M501MB/MA Monitor X 0.0004 = 0.0051/0.0055 =
MIX-M500R(A)/MIX-M500S(A) Addressable Control Module
X 0.0003 = 0.0051 =
MIX-M500X(A) Fault Isolator Module X 0.00045 = 450μA=
B224BI(A) Analog Base with Isolator X 0.00045 = 0.005 =
Four-Wire Smoke Detectors X = =
Signal Load (bells, horns, strobes, and etc.) X =
Auxiliary Power Supply for Remote Annunciators =
Alarm
=
Total currents (Add above currents) STANDBY (A) (B)
