Mircom FleXNet FX-4000 User Manual

124
32.0 QMT-5302NV Vertical Master Telephone
The QMT-5302NV Vertical Master Telephone Module fits into the BBX-FXMNS Enclosure. The
master telephone is mounted to the inside chassis and field wiring is on the BBX-FXMNS
backbox. Connections and terminal wiring are shown in the following instructions.
Figure 80 QMT-5302NV Master Firefighters’ Telephone
